Vision System Automatic Assembly Line Robot QZLLSSD-X
- Brand: Qizhong Dispensing
- Model: QZLLSSD-X
- Origin: NingBo CHINA
- Shipping Terms: EXW/FOB/C&F
- Delivery Time: 5 work day （Except for customization）
- Service: Recommend suitable glue
- Experience: More than 10 years experience in dispensing industry
Introduction
The pipeline-type large-stroke three-axis motion platform replaces the manual operation of large-area and heavy-load products. The XYZ three-coordinate method can program any motion trajectory in the same plane, and the supporting docking station can be connected to the assembly line. It is suitable for 300ml~330ml stick-packed paste glue on the market, and the glue is accurately dispensed by means of precision motor screw drive.
keywords: 3-axisSilicone-glueGantry-Robotic
Gluing Effect
Features
2. Precise quantitative electric push glue for paste glue: It is suitable for paste glue in 300ml~330ml stick packaging on the market, and the glue is accurately discharged by means of precision motor screw drive.
3. Precision glue volume controller for electric glue pusher: It is developed by combining more than 10 years of application experience in the dispensing industry. It not only meets the precise glue output, but also ensures the stability of the machine in glue volume control.
4. Three-axis full screw servo system: The three-axis adopts Panasonic servo system and precision screw drive, which makes the machine have greater load bearing while ensuring the repeatability of the running position.
5. CCD visual aided programming and automatic deviation correction: CCD visual aided trajectory programming and automatic deviation correction function are used to make up for trace errors caused by products, fixtures, dispensing heads and other factors during the dispensing process.
6. PC visual programming: Any graphic trajectory on the same plane can be edited by means of point/line/arc and other instructions on the matching special visual programming software for dispensing.
Advantages To The Business
2. The equipment is equivalent to being a skilled worker from the beginning, and no longer worry about cultivating a skilled worker.
3. Solve the gluing process that cannot be achieved manually, and help break through the bottleneck of product process (such as product gluing precision, uniformity, consistency, etc.).
4. Help to improve the production capacity and quality of enterprise products, and can realize batch replication.
Technical Parameters
| MODEL | QZLLSSD-X |
| Maximum Speed (X&Y/Z) | customize |
| Body Dimensions | customize |
| Distance between Z-axis and worktable | customize |
| Industrial Movement | X/Y/Z three-axis three-linkage |
| Drive System | Panasonic Servo Motor And Servo Drive |
| Transmission Method | Precision Linear Guide And Precision Screw |
| Safety Protection | Photoelectric Sensor |
| Edit Programming | PC Vision Programming |
| Program File Name | word or number or letter |
| Operation interface | Chinese (Simplified) or English (optional) |
| Interpolation Function | Point/line/line segment/arc/full circle/3D trajectory, etc. |
| Test | Separate Button |
| I/O Signals | 4 inputs / 4 outputs |
| XY/Z Maximum Load | 50kg/20kg |
| Power Supply | AC220V±10%/AC，50/60Hz |
| Air supply requirements | 0.5～0.7Mpa, Dry air source |
| Environment Temperature | 0 ～40℃ |
Service
2. 24-hour online services.
3. Lifelong service of equipment best price replace parts.
4. Recommended supporting automation process solutions.
