• Product Image
  • Desktop Industrial Robot With Rotary Axis And Syringe QZ331WZ-B

  • Brand: Qizhong Dispensing
  • Model: QZ331WZ-B
  • Origin: NingBo CHINA
  • Shipping Terms: EXW/FOB/C&F
  • Delivery Time: 5 work day (Except for customization)
  • Service: Recommend suitable glue
  • Experience: More than 10 years experience in dispensing industry

Suitable for the automatic dispensing process of any angle on the side of regular products (such as cylinders, thread coating, etc.).

keywords: 3-axisSyringe-Barrelsrotarythread-coating

Gluing Effect
Gluing Video
1. 30CC/55CC syringe material storage method: suitable for the vast majority of glue, lubricating oil, paint, ink and other micro-dispensing processes on the market.

2. Table-top horizontal mechanism: suitable for automatic dispensing process at any angle on the side of regular products (such as cylinders, etc.).

3. Precision glue volume controller: After more than 10 years of stable application, the stability of the machine in glue volume control is guaranteed.

4. All-aluminum profile frame: The batch mold opening process ensures the consistency of the machine and the weight of the profile ensures the stability of the machine.

5. Hand-held programming teaching box: You can edit the arbitrary angle graphic trajectory on the side of the regular product through commands such as point/line/arc.

Advantages To The Business
1. Alleviate the common problem of difficulty in recruiting workers in many production-oriented enterprises, and replace some manual gluing processes.

2. The equipment is equivalent to being a skilled worker from the beginning, and no longer worry about cultivating a skilled worker.

3. Solve the gluing process that cannot be achieved manually, and help break through the bottleneck of product process (such as product gluing precision, uniformity, consistency, etc.).

4. Help to improve the production capacity and quality of enterprise products, and can realize batch replication.

Technical Parameters
Maximum Speed (X&Y/Z)300 x 360° x 100mm
Body Dimensions600 x 600 x 600mm
Industrial MovementX/Y/Z three-axis three-linkage
Drive SystemPrecision micro-stepping motor and Stepper drive
Transmission MethodTiming Belt/ Precision Linear Guides
Safety ProtectionPhotoelectric Sensor
Edit ProgrammingHandheld Programmer
Program File NameNumbers and letters
Operation interfaceChinese (Simplified)/English, freely switchable
Interpolation FunctionPoint/line/line segment/arc/full circle/3D trajectory, etc.
TestSeparate Button
I/O Signals4 inputs / 4 outputs
X/Y/Z Maximum Load10kg/2kg/3kg
Equipment PowerLess than 500W
Power SupplyAC220V±10%/AC,50/60Hz
Air supply requirements0.5~0.7Mpa, Dry air source
Environment Temperature0 ~40℃
1. Desktop Dispensing Robot is guaranteed for three years.
2. 24-hour online services.
3. Lifelong service of equipment best price replace parts.
4. Recommended supporting automation process solutions.
